FS-300 Maximum View Impact Storefront System

The FS-300 Maximum View is an advanced architectural solution designed to overcome the limitations of traditional butt-glazed systems. Building on the robust foundation of the original FS-300 series, this system eliminates the need for vertical mullions, allowing for a sleek, seam-to-seam glass aesthetic. It is the ideal choice for projects demanding uninterrupted sightlines without compromising on hurricane-grade protection.

Key Benefits

• Seamless Transparency: Achieves a true “glass wall” effect by removing vertical obstructions, creating a seamless connection between indoor and outdoor spaces.

• Expansive Panel Sizes: Supports massive glass panels up to 94″ wide by 157″ high, significantly larger than standard storefront offerings.

• Design Flexibility: Capable of accommodating glass-to-glass butt joints at angles of 35 degrees or greater, offering versatility for corner configurations and unique architectural shapes.

Technical Specifications

• Framing Profile: 1 1/8″ x 3 1/2″ with a 1 1/8″ front set.

• Glass Compatibility: Designed for Triple Laminated Glass (Heat Strengthened SGP) in thicknesses of 1 3/16″ or 15/16″.

• Performance Ratings:

  • Design Pressure: +/- 70 psf

  • Water Resistance: 14 psi

• Dimensions:

  • Max Panel Size (Multiple Panel Run): 94″ x 157″

• Compliance & Testing:

  • Approvals: Florida Building Code (FBC).

  • Testing Passed: TAS 201 (Impact), TAS 202 (Static Load), TAS 203 (Cyclic Pressure), ANSI Z97.

Installation & Glazing

• Flexible Glazing Options: Panels can be pre-glazed (single units) for efficiency or glazed in the field depending on project requirements.

• Advanced Assembly: The system is engineered for straightforward installation while maintaining high-performance weather sealing.
